12v/24v mini diaphragm air pump with bldc motor

  • 12v/24v mini diaphragm air pump with bldc motor
  • 12v/24v mini diaphragm air pump with bldc motor
  • 12v/24v mini diaphragm air pump with bldc motor
  • 12v/24v mini diaphragm air pump with bldc motor

12v/24v mini diaphragm air pump with bldc motor

    Brand: YWfluid
    Transportation: Ocean
    Place of Origin: CHINA
    Port: shanghai

Basic Info

Model No.: YW29-B

Product Description

YW29 miniature vacuum diaphragm pump has high flow and long life. It is suitable for various medical, environmental protection, chemical, biological engineering and Other instruments and equipment. It has an ultra-small volume and supports a variety of motors. Maintenance-free and long life.

YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump

YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump



Item

Flow

Pressure

Vacuum degree

Motor Type

Voltage

Noise level

YW29-B in Parallel

12L/min

0.20Mpa

-0.07Mpa

BLDC/DC

12V

70dB

YW29-B in series

8.3L/min

0.20Mpa

-0.085Mpa

BLDC/DC

12V

70dB


YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump

Product Details

YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pumpYWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump

Product Performance



Pulse Width Modulation (PWM)

Pulse-width modulation is a commonly used technique for controlling DC Motors. 1.The average value of the voltage fed to the motor is controlled by turning a switch between the voltage supply and the motor on-and-off at a fast pace. The longer the switch is on compared to the off time, the higher the power supplied to the motor. 2.The PWM switching frequency varies for different types of devices, and is selected based on how it affects the device. For example, Some applications require a faster switching frequency to reduce the noise or electrical noise that is being heard. 3.The term duty cycle describes the ratio of on-time to the period (one complete on-and-off cycle). Duty cycle is normally expressed as a percentage of on-time, 100% being full-power and 50% being half-power. 4.The advantage of PWM is the reduction of power-loss due to switching versus other control methods. We recommends controlling the pump using 15kHz - 20 kHz frequency range.

The Flow Chart

YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump

Product Photos

YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pumpYWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump

YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump


Company Information


YWfluid 12v/24v mini diaphragm air pump with bldc motor used for laboratory gas transport vacuum pump

Changzhou Yuanwang Fluid Technology Co., Ltd.

 Changzhou Yuanwang Fluid Technology Co., Ltd. is located in Changzhou City, Jiangsu Province, with convenient transportation and comfortable environment. It takes 1 hour by high-speed rail from Shanghai to Changzhou. There are more than 50 Seiko, including professional developers, careful production and strict quality control personnel. Our sales team is always online to meet customer needs.

Our main products are micro pumps, pump control systems, micro peristaltic pumps, micro diaphragm pumps, pipe fittings and accessories, etc. All products can be customized according to your special requirements. Our products are widely used in medical machinery, laboratory equipment, water treatment, printing, automotive products, etc.

Our rigorous attitude towards product quality and the spirit of pursuing the latest technology enable you to gain a higher position in success.
